Baler Shredder
Large-scale baler shredder is to directly enter the bundles and bundles of materials into the rotary cutter to shred the materials. The machine uses a fixed knife and a movable knife to shred the materials. The output is high, and the fresh materials and dry materials can be directly shredded. , The machine performance is stable, and the output is customized according to user requirements
Dimensions (L*W*H):4.5m*2.55m*2.95m
Supporting power:110kw
Application scenarios: Cattle farm, sheep farm
Baler Shredder features
1. The turntable can store a large amount of materials, realize intermittent feeding and continuous work.
2. The inner disc of the rotating disc is designed with a damping plate, which can grasp the bale and rotate it, and the cutting efficiency is high.
3. There are many movable knives, high shredding degree, and the blades are welded with tungsten alloy, which can be used for a long time.
4. The power driving mode can be electric motor driven or tractor PTO driven.
Overview of Baler Shredder
Large-scale baler shredder is to directly enter the bundles and bundles of materials into the rotary cutter to shred the materials. The machine uses a fixed knife and a movable knife to shred the materials. The output is high, and the fresh materials and dry materials can be directly shredded. , The machine performance is stable, and the output is customized according to user requirements
Baler Shredder technical parameters
Nubumer | project name | unit of measurement | test result |
1 | Specifications | / | 130 |
2 | Dimensions (L*W*H) | m | |
3 | structural quality | T | 3 |
4 | Supporting power | KW | 110 |
5 | productivity | t/h | 8-10 |
6 | Kneading length | cm | 3-6 |
7 | Bearing Type | / | F314 |
8 | triangle belt | / | C-1850五条Five |
9 | Drum motor | KW | 3 |
10 | Conveyor motor | KW | 2.2 |
11 | allocator | / | ZT-L12E |
13 | hydraulic motor | / | Bm3-400 |
14 | tire | 10.0-15t wo | |
15 | hammer | / | |
16 | Steel plate thickness | mm | 5mm Drum 5mm Bottom plate 5mm |
17 | starter cabinet | KW | 130KW Autocoupling starter cabinet |
18 | Whole machine test | The top of the barrel is 2.4m, the bottom of the barrel is 2.14m, and the height of the barrel is 1.2m | |
19 | discharge method | / | under discharge |
